POWER LOAD MANAGEMENT CONTROL SYSTEM AND NETWORK UPGRADE
APD Engineering was hired to perform design & implementation of the Power Load Management Control System & Network Upgrade.
APD provide a complete range of on-site field testing and commissioning services for power infrastructure. APD also offer tailored field engineering solutions and other niche services. For example, network audits, performance studies, troubleshooting and investigative support services.
The commissioning team comprises of electrical engineers and technicians with protection systems experience, proficient in conducting power system studies and the preparation of settings for Intelligent Electronic Devices (IED) for voltages up to 500kV. APD own a full suite of testing equipment covering the various tests commonly performed in an electrical environment.
Additionally, our engineers are very familiar with the design, operation and settings requirements for recognised device manufacturers, including GE, ALSTOM (formerly AREVA), SIEMENS, SEL, ABB, Schneider and RMS. This multi-relay skillset and design capability delivers project savings through the deployment of a single team.
To ensure our field engineers meet the project milestones, they are backed by our extensive pool of design and consulting engineers fully equipped with a comprehensive suite of engineering application and drafting software.
APD Testing and Commissioning Engineers have extensive experience in the setting and the testing of legacy analogue devices and Intelligent Electronic Devices (IED) and their respective sensing devices used for protection and control systems in substations for all voltages up to and including 500kV and including but not limited to devices manufactured by; GE, Alstom (AREVA & Schneider), ABB, Siemens (Reyrolle), SEL. Etc. Protection relays will be tested at the proposed setting points or any other points required by the client to confirm correct functionality of the relay. A completed test sheet will be provided for each relay tested including an independent review on the equipment suitability for the function it was installed to do.
APD Testing and Commissioning Engineers can provide immediate resolution of any protection programming or setting issues and any integration issues as they are also expert in power system and protection systems design.
APD have extensive capability in automation and control systems, and their supporting communications and security infrastructure with expertise in SCADA systems. We can provide SCADA/Protection testing and commissioning as an integrated service including DNP3, IEC 61850, IEC 60870, CANBUS & Modbus.
APD Testing and Commissioning Engineers undertake comprehensive testing and commissioning tests on each item of primary plant. The results from these tests are compared to the manufacturer’s data sheets, the relevant standard and if required the client requirements with any non-conformance reported. The table below illustrates the routine site tests carried by APD Testing and Commissioning Engineers, however, non-routine tests and be tailored to satisfy the clients special needs.
PRIMARY DEVICE | TEST REGIME |
---|---|
Generator | Stator DC resistance, stator zero, positive and negative sequence impedance., Rotor AC and DC impedance, dissipation factor, insulation resistance, polarisation index, Partial discharge measurement. |
Power Transformer | Winding ratio, Vector group, DC resistance, Impedance %, tap change continuity/ratio, Insulation resistance, dissipation factor (Tanδ), calibration of thermal sensors, frequency response analysis, oil test and analysis, dirana testing. |
Current Transformer | CT ratio and phase error, CT magnetising curve, CT secondary DC resistance Test, CT secondary impedance test, CT primary and secondary Insulation resistance test, polarity & continuity test. |
Voltage Transformer | VT ratio, VT secondary/primary Insulation resistance tests, polarity & continuity tests, HiPot test. |
Earthing System | Step and touch voltages, system earthing resistance, system integrity. |
Circuit Breaker | Contact resistance for all joints, Insulation resistance, HiPot testing, Trip close timing tests, dynamic resistance measurements. |
Busbar | Partial discharge test, conductivity, insulation resistance. |
Disconnector Switch | Contact resistance for all joints, insulation resistance |
Surge Arrestor | Insulation resistance test, variable frequency dissipation factor measurement, discharge counter check. |
Power Line Testing | Positive and zero sequence impedance measurements, ground fault current compensation factor, mutual coupling of parallel lines, coupling impedances between power lines, and signal cables and pipelines. |
Cables | VLF testing, Partial discharge, insulation resistance, conductivity test. |
APD Testing and Commissioning Engineers undertake comprehensive integration functionality tests to prove that all equipment functions as an integrated unit.
Primary equipment is injected and current/voltage is measured at the relay to ensure that relays are all connected to the correct CTs and VTs with the correct polarity.
Integrated functionality is checked for all devices including; Relay trip contacts, Equipment Interlocks, Logic sequences, Alarm and mimic functions, Transformer cooling system operation, AVR and paralleling systems, Voltage and current systems continuity, CBF busbar protection trips, Voltage selection schemes functionality, Site ancillary services functionality checks etc.
APD Testing and Commissioning Engineers have design expertise and are supported by a design team enabling any design or construction non-conformances to be analysed at site and solutions offered.
TESTING EQUIPMENT:
SOFTWARE:
APD Engineering was hired to perform design & implementation of the Power Load Management Control System & Network Upgrade.
CLIENT: BHP LOCATION: Pilbara, WA. SCOPE: HV Substation SCADA and communications design, configuration, testing & commissioning at Yandi and Junction. TECHNICAL SITUATION Yandi and Junction substations…
Soil Testing, Earthing Design, Conductor Sizing, Step & Touch Assessment, Earth Injection Testing.
Power System Studies, Protection Grading Analysis, Earthing System Design & Site Testing.
Complete design, procurement, testing and construction management for the replacement of an existing 6.6kV Switchboard. Existing switchboard was split into separate boards with a total…
Protection relay testing and commissioning as well as training support.
